Hunter X Hunter Maboroshi No Greed Island English Iso on this page. The Edic Mini Tiny A77 Covert Audio Recorder is the world smallest covert audio recorder and can. Edic Mini Tiny A77 Main. Manual to software: Series.
• Edic-mini Tyny16 Digital Voice Recorder Operation manual Version: 08-09-26 © TS-Market. • Contents..3 Characteristics..4 Overlook. 6 Main Technical Characteristics.7 Recording Duration Depending on the Model.
8 Recording Duration Depending on Compression.10 Working with the Recorder.1 Microphone Amplifier Settings.1 Playing Back the Recordings.1 Recording Methods.13. • Edic-mini Tiny16 Digital Voice Recorder The recorders of the Edic-Mini Tiny 16 family are intended for the professional recording of speech onto a built-in Flash memory card. Then the recordings can be uploaded to the computer. Characteristics - Extremely small size and weight; - Long recording duration: from 18 to 60 hours depending on the model (8 kHz sampling rate, compression algorithm. • Overlook Connect the recorder to a USB computer port using the supplied USB cable. The supplied software is available for Windows 2000/XP. The software allows to save recordings as standard audio files, program the recorder’s settings, use the recorder as a Flash drive for saving and uploading files with sizes from 128 Mb to 4 Gb depending on the model.
• You can set the timer setting in the recorder program: for daily timer (set the time for the beginning and end of the recording) and for once timer (set the date and the time for the beginning and the end of the recording). You can set a password protection in the recorder so unauthorized users will not have access to recorder’s settings and recordings. • Main Technical Characteristics Table 1. Characteristic Value Ratio signal/noise (dB) Mode mono Compression algorithm 1. Without compression 2. ADPCM (2 and 4 bits) Sampling rate 13.3 Frequency band (Hz) 100 – 10,000 PC interface USB 1.1 Data communication rate Up to 5.5 Mb ADC digit capacity 16 bits. • Recording Duration Depending on the Model The recording duration depends on the recorder’s model.
Table 2 shows the data that are in the conditions: the Mono mode, sampling rate is 8 kHz, and ADPCM (2 bits) compression algorithm. Recording duration Built-in Model. • Recording Duration Depending on Compression The recording duration depends on compression. To detect the recording duration that can fit on your recorder’s memory card, check the data shown in Table 3. Evaluate the duration by dividing the recorder’s model index by a correspondent coefficient from the table. • Working with the Recorder Before recording, turn on the recorder.
For different models, there are different ways to turn on the recorder. You can find a full description of how to turn on the recorder in the recorder instruction’s supplements. After you turn on the recorder, start (turn on) recording.
• with a power supply from a rechargeable battery). 1 flash means that the charge is close to maximum, 2 flashes – the charge is enough for work, 3 flashes – you need to change the battery or charge the rechargeable battery.
The second succession corresponds to the amount of the recorder free Flash memory space. • Microphone Amplifier Settings In the recorder, you can set the microphone amplifier settings. You can set a fixed or automatic gain control (AGC). AGC changes the signal amplification automatically depending on the signal level. So you can record a very load audio signal (nearby an audio source) in its true value.
• Voice Activating System (VAS) Voice Activating System allows to reduce (up to 100 times) the memory and power consumption. When you turn on the Voice Activating System, the recorder checks the level of the audio signal.
